Hydraulic Power Unit Pack 12V P/T Circuit

12V Hydraulic Power pack to operate on a pump & tank (P/T) circuit.

12v dc 1.6kw electric motor c/w relay and plastic motor cover.
2.1cc/rev gear pump.
4.5 Litre reservoir c/w drain plug (larger tanks available on request).
Powerpack complete with suction strainer, return oil conveyor and filler breather.
Horizontal mounting
Max pressure 200 bar.
Relief valve set at 160 bar but adjustable from 40-200 bar as standard.
Max flow 5 l/min
Relief valve and P line check
Port size 3/8" BSP.

400 x 198 x 185mm (L x H x D)

Ideal for all applications where a valve chest is already present and all that is needed is pressure and tank ports.
